GRS-WFC3

Jupiter Great Red Spot Velocity Fields from HST/WFC3 (GRS-WFC3)

Primary Investigator: Michael H. Wong

Contributing Program PIs: Amy A. Simon, Imke de Pater, Glenn Schneider

HLSP Authors: Michael H. Wong

Released: 15 April 2021

Updated: 14 July 2021

Primary Reference(s): Wong et al. 2021

DOI: 10.17909/t9-jfs3-p240

Citations: See ADS Statistics

Read Me

Source Data:

HST GO 11559 (Cycle 17), 13067 (Cycle 19), 13937 (Cycle 22), 14334 (Cycle 23), 14661 (Cycle 24), 14756 (Cycle 24), 15159 (Cycle 25), 15262 (Cycle 25), 15502 (Cycle 26), 15665 (Cycle 26), 15929 (Cycle 27)

Animations showing the Great Red Spot over 10 hours. — This is approximately what it would look like if the Great Red Spot were continuously illuminated and viewed for 10 hours. HST/WFC3 data were used to measure the wind flow in and around Jupiter's Great Red Spot. This wind field was used to interpolate how the cloud features changed over one Jupiter day (about 10 hours). In reality, the Great Red Spot would have rotated from day to night to day over this time period, so this movie would be impossible to record directly. The data come from September 2020 Jupiter observations from the Outer Planet Atmospheres Legacy (OPAL) program (Simon et al. 2015). **NOTE**: The original video is available on YouTube.

Overview

High precision velocity fields of Jupiter's Great Red Spot (GRS) have been created by correlating sequences of WFC3/UVIS images spanning typical sequence durations of 10 hours. The analysis, results, and high-level science products are described in a paper by Wong et al. (2021), entitled "Evolution of the Horizontal Winds in Jupiter's Great Red Spot from One Jovian Year of HST/WFC3 Maps." Velocities were measured using the Advection Corrected Correlation Image Velocimetry (ACCIV) software, which was described in Asay-Davis et al. (2009) and is available at GitHub.

Data Products

Three products are provided for each velocity field in the form of .tar.gz files. Each tar file contains groups of additional data files, as
described in the Supporting Information of Wong et al. (2021). The tar file naming convention is as follows:

hlsp_grs-wfc3_hst_wfc3-uvis_<timestamp>-<dataset>_<filter>_v1_<bundle>.tar.gz

where:

<timestamp> = The fractional year, example, "2019.48".
<dataset> = The label of the dataset, example, "grs19opal-d12". Consult the Supplemental Information PDF file available from the primary reference (Wong et al. (2021)) for additional information. The general format is "grs" for Great Red Spot, a two-digit year corresponding to the midpoint time of observation, and an additional designation. "opal" means the observations were taken as part of the OPAL program. "pj" refers to the Juno perijove number. "d12" and "d21" relate to the relative timing of the data used to construct the velocity fiels.
<filter> = The name of the HST filter used, example, "f631n".
<bundle> = The type of data files in this bundle, one of "inputs", "output-analysis", or "output-data".

Data file types:

_inputs.tar.gz	These collections of text and HDF5-format binary data are required as input to the ACCIV velocity retrieval code. ACCIV uses an iterative approach, and parameter files included in this bundle describe all parameter values needed to control the successive iterations of the retrieval. Binary grid files are included to specify the geometry of the data, and the cylindrically-projected HST data, after application of limb darkening corrections, are included as numbered frames. A full description of the parameters and the format of the HDF5 input data can be found at the ACCIV GitHub repository. There is only one set of input HDF5 binary files for each epoch, although every candidate velocity field at that epoch has its own separate input text files. It is recommended to download all the _inputs.tar.gz files for the desired epoch; only one of these will include the binary input files.
_output-analysis.tar.gz	These bundles contain human-readable plots and maps (in PDF format), along with text files containing some tabular data used to generate the plots plus other quantities measured from the velocity fields.
_output-data.tar.gz	These bundles contain two binary files in HDF5 format. These data files describe the velocity field retrieved by the ACCIV process. These are the files most likely to be directly useful for further analysis. The ACCIV GitHub repository and primary reference (Asay-Davis et al. 2009) should be consulted to understand how these data fiiles are derived. Briefly, the included data files are: outGridVelocity.h5 - Velocities in the x- and y-directions are interpolated onto a regular grid in latitude and longitude. outScatteredVelocity.h5 - Individual velocity vectors are given, prior to gridding.

_inputs.tar.gz

These collections of text and HDF5-format binary data are required as input to the ACCIV velocity retrieval code. ACCIV uses an iterative approach, and parameter files included in this bundle describe all parameter values needed to control the successive iterations of the retrieval. Binary grid files are included to specify the geometry of the data, and the cylindrically-projected HST data, after application of limb darkening corrections, are included as numbered frames. A full description of the parameters and the format of the HDF5 input data can be found at the ACCIV GitHub repository.

There is only one set of input HDF5 binary files for each epoch, although every candidate velocity field at that epoch has its own separate input text files. It is recommended to download all the _inputs.tar.gz files for the desired epoch; only one of these will include the binary input files.

_output-analysis.tar.gz

These bundles contain human-readable plots and maps (in PDF format), along with text files containing some tabular data used to generate the plots plus other quantities measured from the velocity fields.

_output-data.tar.gz

These bundles contain two binary files in HDF5 format. These data files describe the velocity field retrieved by the ACCIV process. These are the files most likely to be directly useful for further analysis. The ACCIV GitHub repository and primary reference (Asay-Davis et al. 2009) should be consulted to understand how these data fiiles are derived.

Briefly, the included data files are:

outGridVelocity.h5 - Velocities in the x- and y-directions are interpolated onto a regular grid in latitude and longitude.

outScatteredVelocity.h5 - Individual velocity vectors are given, prior to gridding.

Data Access

UT Date (Series Midpoint)	Fractional Year	Dataset Label	High Level Science Products
2009-09-22 16:37	2009.72	grs09	input \| output-data \| output-analysis
2012-09-20 15:42	2012.72	grs12	input \| output-data \| output-analysis
2015-01-19 13:53	2015.05	grs15p4	input \| output-data \| output-analysis
2015-01-19 13:53	2015.05	grs15p5	input \| output-data \| output-analysis
2016-02-09 16:03	2016.11	grs16opal-d12	input \| output-data \| output-analysis
2016-02-09 16:03	2016.11	grs16opal-d21	input \| output-data \| output-analysis
2016-12-11 19:42	2016.94	grs16pj03	input \| output-data \| output-analysis
2017-02-01 22:50	2017.09	grs17pj04-d12	input \| output-data \| output-analysis
2017-02-01 22:50	2017.09	grs17pj04-d21	input \| output-data \| output-analysis
2017-02-01 22:50	2017.09	grs17pj04-long	input \| output-data \| output-analysis
2017-04-03 08:08	2017.25	grs17opal-long	input \| output-data \| output-analysis
2018-04-17 07:49	2018.29	grs18opal-d12	input \| output-data \| output-analysis
2018-04-17 07:49	2018.29	grs18opal-d21	input \| output-data \| output-analysis
2019-04-09 18:44	2019.27	grs19pj19	input \| output-data \| output-analysis
2019-06-26 12:46	2019.48	grs19opal-d12	input \| output-data \| output-analysis
2019-06-26 12:46	2019.48	grs19opal-d23	input \| output-data \| output-analysis
2020-09-20 08:15	2020.72	grs20	input \| output-data \| output-analysis

Citations

Please remember to cite the appropriate paper(s) below and the DOI if you use these data in a published work.

Note: These HLSP data products are licensed for use under CC BY 4.0.
